2015--LF series Flowlevel Indicator/Controller

FOB Reference Price:Get Latest Price
$60.00 - $90.00 / Pieces | 5 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Mypin
Model Number:
LF
Display Type:
Digital Only
Measuring Range:
AC 90-260V 50/60HZ
Accuracy Class:
0.3%
Supply Voltage:
regular:80--265VAC/DC
Operating Temperature:
0(32F)-50(122F)℃
Dimensions:
96*48*80
Weight:
<500g
Display:
6 digits dual line
Communication:
RS232 RS485
Flow Controller:
Flow Controller
Supply Ability
Supply Ability:
200 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
each pieces packed in box lined with plastic bag,then every 30 or 50 box in carton
Port
Shenzhen

2015--LF series Flowlevel Indicator/Controller



The Red LED displays: the accumulated flow

The Green LED displays: the instantaneous flow





Product Description



1,The instrument applys for gas/liquid flow measurement.eg.saturated

   steam,over-heat steam,compressed air,etc.With temperature and pressure c

   ompesation to gas/liquid density,which can be adjustable b software.In

   addition,applications in various auto control system,such as ampermeter in

   eletroplation industry.

2,Dual line 6 digit display,display instantanous/accumulated/batch flow value.

   Accuracy:3%.

3,Input: 0-5A, 4-20mA, 0-10V, 0-75mV, 0-10KHz, Pt100, Tc(K J E), or

   Compensation input.

4,Alarm output:up to 4 alarms & various control modes,For example, quantitative

   control flow,process control and auto restart conversion, auto restart conversion

   control output. etc..

   Analog output: 4-20mA or 0-10V  output for instantanous/accumulated level

5,Auxiliary power: 2-wire 12V/24V/30mA.

6,Standard RS232/RS485 communication interface,MODBUS RTU protocol.Can connect to other

   equipments/PC/PLC for remote control.





Packaging & Shipping





1.The complement packing contains 1 meter, 1 manual and 1 pair of brackets.

2.Items are usually shipped within 3 to 15 business days after payment has been received, which according to the quantities.

3.Shipment is by Sea, Freight or Courier(DHL/FEDEX/TNT/UPS/EMS/CHINA POST MAIL) as per clients request.





Our Services



  • We provide 18 months warranty for all Mypin products.
  • OEM / ODM service available to meet up to client's requirements
  • Any questions, please mail or call us any time

Company Information



Main product:Panel Meter

                     Counter

                     Weighing indicator

                     Temperature/Humidity Controller

                     Current/Voltage/Power meter,various sensor indicator

                     Frequency / Tacho / Batch / Length /Linespeed Meter

                     Flow / Level /Pressure Controller

                     Proximity/ Photoelectrical Switch

                     Timer,Timer Relay

                     Sensor Controller

                     Signal adjustor

  They are widely used in industrial control and measurement field, such as machinery, electrical cabinet, power sub-station, industrial automation, etc..



  Additonally,OEM service,Design service offer, Buyer laber offer.
