each pieces packed in box lined with plastic bag,then every 30 or 50 box in carton
Digital encoder pulse Counter set (counter FH8-6CRNB + encoder RJ38-6/1000-YC)
The set of Length/Position controller consists of one digital length/position controller FH7-6CRNB and one wheeled length sensor MLK-80. It's widely used in machinary of printing, packing, textile,plastic & rubber, cable $ wiring, mechnical and any other production line for auto length dection.
By means of the reverse rolling friction between drive gear and the measured objects(such as textile or plastic tape) or the reverse rolling tetween drive gear and the main shaft of machine producing the measured objects, the sensor sends photoelectrical signals to the controller(FH7-6CRNB). The controller will turn the photoelectrical signals to digital signals and display the the accumulated length..
Display: dual line 6 bit LED
Counting range: -199999~999999
Coefficien set up range:0.00001~99999.9
Output: relay( AC 250V/3A,DC 30V/3A cos¢=1.
Output mode: R.N,C.F.H,L
Input resistance: ≥10KΩ
Environment:0-50C, 35-85% RH
Aux. power:24V DC +/-5% 30mA max.
power off memory :over 10years(25°c) .
Packaging & Shipping
1.The complement packing contains 1 meter, 1 manual and 1 pair of brackets.
2.Items are usually shipped within 3 to 15 business days after payment has been received, which according to the quantities.
3.Shipment is by Sea, Freight or Courier(DHL/FEDEX/TNT/UPS/EMS/CHINA POST MAIL) as per clients request.
We provide 18 months warranty for all Mypin products.
OEM / ODM service available to meet up to client's requirements
