LM Weight electronic controller for filling and packaging machine

FOB Reference Price:Get Latest Price
$20.00 - $60.00 / Pieces | 5 Piece/Pieces (Min. Order)
Type:
Weigh Beam
Rated Load:
9999
Accuracy:
0-9999
Lead Time:
Quantity(Pieces) 1 - 100 101 - 1000 >1000
Est. Time(days) 4 15 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China
Brand Name:
Mypin
Model Number:
LM
Power Supply:
110/220V or 18-30V AC/DC
Display Type:
4 digits LED display
Power consumption:
<5VA
Sampling speed:
16 times/sec.
Accuracy:
3%
Input:
1-4 loadcells
alarm output:
relay/SSR
Analog Output:
0-10V/4-20mA
Communication:
RS 232 or RS 485 MODBUS RTU protocol
Unit:
Gram/KG/Ton/Newton/Pound, etc.
Size:
48*96*80mm
Product name:
Weight controller
Supply Ability
Supply Ability:
1000 Set/Sets per Week
Packaging & Delivery
Packaging Details
each pieces packed in box lined with plastic bag, then every 30 or 50 box in carton
Port
Shengzhen
Lead Time :
Quantity(Pieces) 1 - 100 101 - 1000 >1000
Est. Time(days) 4 15 To be negotiated
Video Description

LM Weight electronic controller for filling and packaging machine



Product Description





 Features:



 1. Input:various electronic strain transducer or load transducer.High responsd,precision,up to 6 segments controller with switch of start/pause/charging/discharging.,easy to operate.Have functions as date or peak value holding,tare weight clearing,accumulated or mean value calculation.Widely used in various industrial weighing system,such as truck weighing/grevimatric filling machine,etc.

2. Output: up to 6 segments batch controll,selectable freely.

     Isolated current output 4-20mA or 0-10V,range settable.

3. Sensor power supply,output 12V/30mA or +24V/40mA,

4. High accuracy, 4 digits display,range:0.00001~99999,demical point floating setting.

5. RS232 or RS485 Modbus RTU protocol,connectable with various equipment,computer or PLC directly.

6. Width power supply: regular:90-260V AC/DC,  others:12V DC or 24V DC.

7. Dimemsions:     LA8: 48*96*80   Case class:IP65.

LA8 series ,4 digits dispaly,accuracy:0.3%;







Packaging & Shipping





1.The complement packing contains 1 meter, 1 manual and 1 pair of brackets.

2.Items are usually shipped within 3 to 15 business days after payment has been received, which

   according to the quantities.

3.Shipment is by Sea, Freight or Courier(DHL/FEDEX/TNT/UPS/EMS/CHINA POST MAIL) as per

  clients request.





Our Services



  • We provide 18 months warranty for all Mypin products.
  • OEM / ODM service available to meet up to client's requirements.
  • Any questions, please mail or call us any time.



Company Information



Main product:Panel Meter

                     Counter

                     Weighing indicator

                     Temperature/Humidity Controller

                     Current/Voltage/Power meter,various sensor indicator

                     Frequency / Tacho / Batch / Length /Linespeed Meter

                     Flow / Level /Pressure Controller

                     Proximity/ Photoelectrical Switch

                     Timer,Timer Relay

                     Sensor Controller

                     Signal adjustor

  They are widely used in industrial control and measurement field, such as machinery, electrical cabinet, power sub-station, industrial automation, etc..



  Additonally,OEM service,Design service offer, Buyer laber offer.
