FA8 series 5 Digit Display Frequency Tacho Counter,HZ Meter, RPM Counter Meter
1, Input: various wave form pulse signal (proximity switch,photoelectrical switch or AC
signal, etc), contact switch, encoder, etc, used to measure power frequency (AC 0--
600V), range: 0.01Hz--100KHz (max 100KHz), accuracy: 0.01Hz.
Applicable to equipment for control of frequency, tacho, line-speed, level, etc; The instrument has
several parameters setting function, easy to operate.
2, For other specialize teser for pulse width, duty cycle, etc, please indicate when ordering;
3, 4/5/6 digit display, with demical point switched automatically; Opical isolation for input and
4, Output: up to 3 alarm output with various output modes selectable; high value, low
value, intervals, etc. analogue output 4-20mA or 0-10mA with range settable.
5, RS232 or RS485 Modbus RTU protocol, connectable with various equipment, computer or PLC
6, Width Power supply: regular: 90-260V AC/DC, others: 12--30V AC/DC indicate when ordering.
7, Dimemsions: FA8: 96*48*80
1.The complement packing contains 1 meter, 1 manual and 1 pair of brackets.
2.Items are usually shipped within 3 to 15 business days after payment has been received, which according to the quantities.
3.Shipment is by Sea, Freight or Courier(DHL/FEDEX/TNT/UPS/EMS/CHINA POST MAIL) as per clients request.
Main product:Panel Meter
Current/Voltage/Power meter,various sensor indicator
Frequency / Tacho / Batch / Length /Linespeed Meter
Flow / Level /Pressure Controller
Proximity/ Photoelectrical Switch
They are widely used in industrial control and measurement field, such as machinery, electrical cabinet, power sub-station, industrial automation, etc..
Additonally,OEM service,Design service offer, Buyer laber offer.
