MYPIN 4 digits LED Weight electronic controller for filling and packaging machine
1. Load cell signals input,eg.0-24mV or 14 PCS loadcells ,with high response,easy to
operate,Have functions as clearing tare weight,displaying modification,weight adjustment and
data/peak value holding; Up to 2 load cells,accumulation or mean value are available,work with
various pressure sensor and weight sensor.Special requirements can be customized.
2. Output:Isolate analogue current output: 4-20mA with range set freely;up to 6 alarm
outputs.Widely used for batching and strain control.
3. Isolated sensor power supply,output +12/5V DC.
4. High accuracy, 4 digit display,1g/1000g.
5. RS232 or RS485 Modbus RTU protocol,connectable with various equipment,computer or PLC
6. Width power supply: regular: 220VAC/110VAC, others: 12V DC/24V DC.
7. Dimemsions: LM8:96*48*80 LM4:48*48 *80 LM10:160*80*70, Case class: IP65.
1.The complement packing contains 1 meter, 1 manual and 1 pair of brackets.
2.Items are usually shipped within 3 to 15 business days after payment has been received, which according to the quantities.
3.Shipment is by Sea, Freight or Courier(DHL/FEDEX/TNT/UPS/EMS/CHINA POST MAIL) as per clients request.
Main product:Panel Meter
Current/Voltage/Power meter,various sensor indicator
Frequency / Tacho / Batch / Length /Linespeed Meter
Flow / Level /Pressure Controller
Proximity/ Photoelectrical Switch
They are widely used in industrial control and measurement field, such as machinery, electrical cabinet, power sub-station, industrial automation, etc..
Additonally,OEM service,Design service offer, Buyer laber offer.
